Energy absorption tester

Energy absorption tester

1 INR/Set

Product Details:

X

Price And Quantity

  • 1 INR/Set
  • 1 Set

Trade Information

  • Cash Advance (CA)
  • Wooden box
  • Asia
  • All India
  • BIS purpose only

Product Description

with simplex or duplex frames50-c17x1/fr and c-shaped open-structure 300kn frame 50-c1601/fr:
round lower support frame for fiber-reinforced concrete round, slabs, 800 mm dia, 75 mm thick, complete with an upper element for the concentrated load. Conforming to ASTM c1550.
50-c1500/9
50-c1500/8 50 mm central slab deflection displacementtransducer

as alternative:
50-c1700/8 60 mm central slab deflection displacement transducer

Square slabs testing toen 14488-5
with simplex or duplex frames50-c15x1/fr or 50-c17x1/fr and c-shaped open-structure 300kn frame 50-c1601/fr:
50-c1500/6 auxiliary testing frame for energy absorption test on sprayed concrete specimens 600x600x100 mm, including supporting square base and loading element. Conforming to en 14488-5.
50-c1500/9 100mm piston travel displacementtransducer
50-c1500/8 50 mm central slab deflection displacementtransducer



This test has to be performed with a suitable flexural frame having proper stiffness and capacity as, for instance, our models 50-c15xx/fr or 50-c17xx/fr, and a control console capable of applying load in displacement control as our model MCC or auto max multi-test.

The test can be carried out on square or round slabs according to en standard or ASTM standard.

In both cases, the test set includes a supporting frame for the sprayed slab, a loading spherically seated punch, and a displacement transducer for central slab deflection measurement.

Testing to ASTM can be performed only in the flexure frames having 300kn or 350kn capacity.
